Certified Acme TB81303 1-Phase Industrial Control Transformer 208/277/380-Volt Primary 95/115-Volt Secondary 100 VA

Acme 1-Phase Industrial control transformer has primary voltage rating of 208/277/380-Volts and secondary voltage rating of 95/115-Volts. Floor mountable transformer has frequency rating of 50/60-Hz and power rating of 100 VA. It measures 3.75-Inch x 4.45-Inch x 3.4-Inch. This transformer withstands temperature rating of 80 deg C. Transformer is UL listed, CSA certified and meets ANSI/NEMA/OSHA standards.

Special Features:Open core and coil; Acme’s TB series industrial control transformers are especially designed to accommodate the momentary current inrush caused when electromagnetic components are energized without sacrificing secondary voltage stability beyond practical limits; Acme industrial control transformers are dry-type, step-down transformers with the secondary control circuit isolated from the primary line circuit to assure maximum safety; Voltage regulation of Acme industrial control transformers exceeds standards recommended by the national electrical manufacturers association, secondary circuit voltage drop between no-load and momentary overload remains exceptionally low; This excellent secondary circuit voltage regulation assures reliable operation of electromagnetic components and may permit the use of a smaller and less expensive industrial control transformer; Constructed with high quality silicon steel lamination to minimize core losses and increase efficiency; Designs incorporate precision split bobbin wound coils for improved regulation; series-parallel connecting links save wiring and labor costs; Terminal blocks allow full access for ring terminals for easy installation even with solid strand conductors; Integrally molded terminal blocks with isolation barriers to prevent arc over; Copper windings on all groups; Heavy gauge steel mounting plate adapts to various mounting dimensions; Provids a low and safe control voltage for the operation of electromagnetic devices requiring above average voltage regulation when actuated; 10-year limited warranty
