00152ET3E182TC-S Hot Deal

WEG Electric S premium efficiency AC induction motor, general purpose and inverter rated, 1-1/2hp, 3-phase, 208-230/460 VAC, 1200rpm, TEFC, NEMA 182TC frame, rolled steel, C-face/rigid base mount.

Brand: WEG Electric
Item: Motor
Series: S
Efficiency Group: Premium efficiency
Efficiency: 87.5
Voltage Type: AC
Motor Type: Induction
Motor Application: General purpose and inverter rated
Horsepower Rating: 1-1/2hp
Number of Phases: 3
Voltage Rating: 208-230/460 VAC
Synchronous Speed: 1200rpm
Nameplate RPM: 1170rpm
Overload Type: None
Enclosure Type: TEFC
Shaft Type: Round with square key
Shaft Diameter: 1-1/8in
Shaft Material: 1045 carbon steel
Motor Frame: NEMA 182TC
Frame Material: Rolled steel
Electrically Reversible: Yes
Insulation Class: Class F
IP Rating: IP55
Constant Torque Rating: 4:1
Variable Torque Rating: 1000:1
Service Factor: 1.15
Integrated Brake: No
NEMA Design: Design B
Junction Box Orientation: F1
Mounting: C-face/rigid base
Mounting Orientation: Horizontal or vertical
Additional Information: Class I Div 2 hazardous rating
